374,41 €
Uvedená cena je platná k 02.06.2024
Aruba Instant On 1930 24G Class4 PoE 4SFP/SFP+ 195W Switch (JL683B) I/O Ports and Slots 24 RJ-45 autosensing 10/100/1000 Class 4 PoE ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10-BASE-T/100BASE-TX: polovica alebo úplná; 1000BASE-T: full only 4 SFP+ 1/10GbE ports Physical Characteristics Dimensions 17.42(w) x 10.42(d) x 1.73(h) in (44.25 x 26.47 x 4.39 cm)(1U height) Weight 7.69lb (3.49kg) Processor and Memory ARM Cortex-A9 @ 800 MHz, 512 MB SDRAM, 256 MB flash; packet buffer: 1.5 MB Packet Buffer 1.5 MB Performance 100 Mb latency < 4.7 uSec 1000 Mb latency 10000 Mb latency Throughput (Mpps) 95.23 Mpps Capacity 128 Gbps Routing table size (# of static entries) 32 MAC address table size (# of entries) 16,000 Reliability MTBF (years) 76 Environment Operating temperature 32°F až 104°F (0°C až 40°C) Operating relative humidity 15% až 95% pri 104°F (40°C) Non-operating temperature -40°F až 158°F (-40°C až 70°C) Non-operating relative humidity 15% až 95% pri 140°F (60°C) Altitude Up to 10,000 ft (3.048 Km) Acoustic1 LWAd = 3.9 Bel LpAm (Bystander) = 25 dB Poznámka:1Acoustics measured v 23°C semi-anechoic chamber with loading of 100% traffic and 50% PoE on all ports. Measured in accordance with ISO 7779. Declared in accordance with ECMA-109:2010. Values sú uvedené ako deklarované A-Weighted Sound Power Level (LWAd) a mean Bystander A-Weighted Sound Pressure Level (LpAm) Electrical Characteristics Frequency 50-60 Hz AC voltage 100 - 127 / 200 - 240 VAC Current 2.8 A/1.4 A Maximum power rating 248.7W Idle power 19.7W PoE power 195 W Class 4 PoE Power supply Internal power supply Safety UL 60950-1; IEC 60950-1;EN 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60825-1 UL 62368-1 Ed. 2; IEC 62368-1 Ed. 2; EN 62368-1:2014 Emissions VCCI-CISPR 32, Class A; CNS 13438; ICES-003 Issue 6 Class A; FCC CFR 47 Part 15, Class A; EN 55032: 2015 +AC:2016 / CISPR-32, Class A Immunity Generic CISPR 24 / CISPR 35 EN EN 55024:2010 / EN 55035:2017 ESD IEC 61000-4-2 Radiated IEC 61000-4-3 EFT/Burst IEC 61000-4-4 Surge IEC 61000-4-5 Conducted IEC 61000-4-6 Power frequency magnetic field IEC 61000-4-8 Voltage dips and interruptions IEC 61000-4-11 Harmonics IEC 61000-3-2, EN 61000-3-2 Flicker IEC 61000-3-3, EN 61000-3-3 Device Management Aruba Instant On Cloud; Web browser; SNMP Manager Mounting Mounts in an EIAštandard 19 in. telco rack or equipment cabinet. 2-post rack kit included Supports table-top mounting Supports rackmounting Supports wall-mounting with ports prispôsobiť either up or down Supports under-table mounting using the brackets provided Transceivers Aruba Instant On 1G SFP LC SX 500 OM2 MMF Transceiver (R9D16A) Aruba 1G SFP LC LX 10km SMF Transceiver (J4859D) Aruba Instant On 1G SFP RJ45 T 100m Cat5e Transceiver (R9D17A) Aruba Instant On 10G SFP+ LC SR 300m OM3 MMF Transceiver (R9D18A) Aruba 10G SFP+ LC LR 10km SMF Transceiver (J9151E) Aruba Instant On 10G SFP+ do SFP+ 1m DAC (R9D19A) Aruba Instant On 10G SFP+ do SFP+ 3m DAC (R9D20A) Aruba Instant On 1930 Switch Series High-Performance, Smart-Managed Switches Designed with Small Businesses in Mind Whether you own a kaviareň, a dizajn firmy alebo tech startup, reliable a secure network plays a kritické role v úspechu vášho podnikania. And you need a network solution thive gives you pece of mind, thought you to focus on rowing your business instead of managing problems with your network. Aruba Instant On makes it easy to keep network users šťastné, mobilné a IoT devices connected, and your network secure. Aruba Instant Na 1930 prepínače funkcie rozšírené, smart-managed, fixed- configuration Gigabitové prepínače designované pre malé businessy, ktoré sú jednoduché-to-deploy and affordable. They're made to handle všade s bandwidth-heavy applications ako voice and video conferencing, integrovať connectivity k enhance performance. Pomocou jej Instant na mobilnej aplikácii alebo cloud-based web portál, môže byť rýchly set up, monitor a manažovať 1930 spínačov série z ničoho v priebehu jedného času. What's more, up to 30 W PoE power delivery je dostupný od-the-box pre vaše triedy 4 PoE devices, ako prístupové body, surveillance kamery a VoIP telefóny, všetky easily managed from the same platform. Vytvorenie security features protect vaše siete z unauthorized prístupu, ktoré umožňujú váš segment dopravy a definovaný prístup do každej oblasti siete. A všetky tieto sú zahrnuté v cene hardvéru - nie sú hidden subscription or licensing fees. Key Features Smart-managed layer 2+ Ethernet switch series ready to deploy in 8-, 24-and 48-port for non-PoE and Class 4 PoE modelsPoE to power APs and IoT devices ako IP phones, surveillance kamery and door locksDve (2) 1G SFP fiber porty na 8-port modeloch, a 4 (4) 1G/10G SFP+ fiber porty na 24-/48-port modely na eliminačné traffic bottlenecks cez váš sieťSecurity controls rokov you define access in each area of your network, keeping your business data safeConvenient mobile app and web-based GUI pre set up, management and troubleshooting. Štandard Features Simplicity at Its Best Plug-and-play switches that work together with Instant On APs right out of the boxMobile app to easily setup, monitor and manage your network Security You Can Count On Protect your network from unauthorized access with IEEE 802.1X and VLANsAutomatic denial-of-service (DOS) monitory and protects the network against malicious attacks We've Got You Covered No extra licensing or subscription feesIndustry-leading limitovaný životný čas warranty and support. The Instant On Differentiators Easy Setup and Management Aruba Instant On mobile app allows you to set up, manažment, a monitor Instant On switches a prístupové body priamo z vášho telefónu. Within the app, môžete získať inšpekcie step-by-step nainštalovať Instant On devices na získanie vašej siete a beh quickly - no technical expertise required. And cloud-based access allows you to access the network from anywhere, at any time. Non-intrusive, Aesthetic Design Aruba Instant On switches sú navrhnuté na complement šľapky a čistý pohľad na Instant na prístupových bodoch, a to blend discreetly do vášho prostredia siete. 8-port modely, ako dobre ako 24- a 48-port non modelov PoE, sú fan-less, ktoré majú ideálny pre office deployments. High Performance with Flexible Options Séria sérií zahŕňa štyri (4) triedy 4 PoE switches, a tri (3) non-PoE switches, ktoré zahŕňajú 8-24- a 48-port Gigabit Ethernet switches. Dva (2) oddelené 1G SFP fiberové porty na 8-portové modely, a štyri (4) dedičované 1G/10G SFP+ fibrové porty na 24-/48-portové modely, zabezpečujú vysokú výkonnosť a eliminujú traffic bottlenecks cez sieť. Customizable features include basic Layer 2 features com VLANs and link aggregation, as well as advanced features such as Layer 3 IPv4 static routing, ACLs, and Spanning Tree Protocols, and IPv6 Host mode. Optimized User Experience Aruba Instant na mobilných aplikáciách vykonávajú spoločné workflows pre Instant na spínačoch a prístupových bodoch, ktoré umožňujú nainštalovať, monitor a manažment vašej siete remotely bez potreby pre doplnkový hardvér ako cloud keys alebo VPN. Môžete tiež update firmware na vaše Instant On devices priamo z cloud whenever you want, z wherever you are. Site inventory Site inventúry feature on Instant On Mobile app ukazuje, že všetky spínače a AP's na single screen, umožňujúce rýchly identify non-functioning devices a troubleshoot accordingly. Multi-Site Management Cloud-hosted web interface a mobilný aplikácia make it easy to management multiple sites, multiple networks, distributed deployments a multi-tenant deployments. Všetky stránky sú logicky oddelené a majú svoje vlastné configuration, štatistiky, guest portál, a admin read/write privileges. Built-In Security Vytvorenie security features protect vaše siete z externých threats by zablokovanie malware útoky a čítanie unauthorized users off the network. Network traffic môže byť filterovaný a prístup obmedzene založený na MAC a IP adrese. No Hidden Fees Všetky features sú zahrnuté v cene hardvéru - nie sú recorreng subscription or licensing fees. Expert-level support a industry leading limitovaný životný čas warranty sú tiež zahrnuté, spolu s chatovou podporou pre život produktu. Management Cloud-Based Management for Entire Network Cloud-hosted web interface a mobilný aplikácia make it easy to manažérske siete s Instant On APs and Switches. Simple Local Web GUI Management Pre riadenie individuálnych spínačov, intuitívne Web GUI umožňuje manažment simple, dokonca pre non-technical users. Supports up to five (5) HTTP a HTTP Secure (HTTPS) sessions. Firmware Update Vykonávať notifikáciu najnovšieho firmvéru s schopnosťou schedule update at prefered time through Instant On mobile app and cloud-based web portal. Default DHCP Client Mode Slúži na switch, aby sa priamo pripojil k networku, zapojil plug-and-play operation. V absencii of servera DHCP na sieť, spínače spadajú späť do statickej address 192.168.1.1. Port Mirroring Enable traffic on a port alebo VLAN to bude simultaneously a network analyzer for monitoring. Event Logging and Alerts Provides detailed information for problem identification and resolution. Account Management Allows administrators to add, modify, delete and transfer management účtov a passwords pre bezpečný prístup k Instant cloud management solution. Locator LED Allows users set locator LED on a špecifický switch to either turn on, blink, or turn off; simplifies troubleshooting by making it easy to locate a particular switch within rack similars switches. Schedule Configuration Global Schedule sa môže aplikovať na time-based ACLs, port alebo interface shutdown, alebo PoE power delivery; up to 3 schedules can be configured. PoE scheduling allows user to configure a špecifický day/time of week (eg business hours) pre Instant On switches to supply power to connected devices (eg surveillance kamery, prístupové body etc.). Quality of Service (QoS) Traffic Prioritization Vytvára time-sensitive balíky (like VoIP a video) s prioritou nad inými nákladmi na základe DSCP alebo IEEE 802.1p klasifikácie. IEEE 802.1p/Q VLAN Tagging Delivers data to devices na základe priority a typu traffic; supports IEEE 802.1Q. Class of Service (CoS) Sets the IEEE 802.1p/DSCP priority to queue mapping (4 queues). Supports strict priority queuing (SP) alebo weighted round robin (WRR) queuing. SP a WRR upravuje možnosť configured on individual switch ports. Advanced Classifier Based QoS Classifies traffic using multiple match criteria na základe 2., 3. a 4. rokov. Access Switching SFP/SFP+ Fiber Connectivity Provides fiber connections pre uplinks a iné pripojenia cez dlhé dištancie than copper cabling can support. SFP porty sú dodané do dostupných ethernetových kópií, tvoria vysoký počet dostupných portov. Dve (2) SFP 1G porty dostupné na 8-portových modeloch a 4 (4) SFP+ 1G/10G portov na 24-/48 port modeloch. Ethernet Alliance Certified Class 4 PoE (IEEE 802.3at) Poskytuje až 30 W na port, ktorý umožňuje podporu triedy 4 PoE schopné zariadenia suché ako video IP telefóny, bezdrôtové prístupové body, a advanced pán/tilt/zoom bezpečnostné kamery, ako 15.4 W IEEE 802.3af- device; mitigates náklady na prídavné elektrické káblové a obvody, ktoré by mohli byť opotrebované v IP telefóne a WLAN deployments. Auto-PoE Power Configuration Switch automaticky identifikuje potrebnú energiu do portu pre PD zariadenie na báze Link Layer Discovery Protocol (LLDP). PoE Power Allocation Support multiple methods (LLDP-MED automatic, class of PoE, or usage-based) to allocate PoE power pre more efficient energy savings. Auto MDI/MDI-X Adjusts automatically pre straight-through alebo crossover cables on all 10/100/1000 ports. Network Security TPM-Based Security Includes a Trusted Platform Module (TPM) pre bezpečný hardvér-založené generácie a skladanie cryptographic keys použitý pre secure connection do Instant On cloud portal. IEEE 802.1Q VLAN Support Support for up to 256 VLANs with VLAN ID range of 2-4093. IEEE 802.1X Access Control Authentication of network users on a port basis prior to permitting network access. Port authentication includes RADIUS asignované VLAN, dynamické VLAN creation, guest VLAN alebo into an unauthenticated VLAN. Automatic Denial-of-Service Protection Monitory pre maličké útoky a protects siete by zablokovali útoky. Packet Storm Protection Protects against unknown unicast, broadcast a multicast búrky s user-defined thresholds. RADIUS Switch supports RADIUS authentication with primary and backup server configuration. Automatic VLAN Assignment - RADIUS Assigned VLANs Automatické prihlásenie používateľov do prispôsobenia VLAN založené na ich identite a umiestnení. RADIUS Accounting A robustný súbor atributov a štatistických údajov je k dispozícii pre collecting information from the switch. Management VLAN ID Provides secure management access to administrators in the specified VLAN. Link Flap Prevention Zníženie siete disrupcie by automaticky detekovalo a rozdeľovalo porty, ktoré experimentujú link flap events. Performance and Efficiency Energy Efficient Ethernet (EEE) Compliant with IEEE 802.3az štandardné requirements to save energie počas obdobia nízkych údajov aktivity. Auto-Port Shut Down Switch saves power by automaticky shutting down power to inactive ports. Power je restored on a port upon link detection. Energy Savings Status Switch provides estimated cumulative energy savings due to green Ethernet features being enabled. Energy-Efficient Cooling Includes variable speed fans operačný len pri rýchlosti necessary do maintain operating temperature to redukcia excess noise and power consumption. Fan-Less Operation Fan-less dizajn pre 8-port modely, 24- a 48-port non-PoE modely, umožňujúce spínače ideálne pre office deployments. Switching Features IEEE 802.3x Flow Control Provides a flow-throttling mechanizmus propagated cez sieť k prevent packet loss at a congested node. Spanning Tree Protocol (STP) Supports štandard IEEE 802.1D STP, IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) pre faster konvergencie, a IEEE 802.1s Multiple Spanning Tree Protocol (MSTP on local web). Loop Protection Ak sú spínače detekcie a loop, to je schopný zdroj prípojného zdroja z forwarding dátových balíkov originating z spínačov do avoid broadcast storms. BPDU Filtering Drops BPDU packets when STP is enabled globally but disabled on a specific port. Jumbo Frame Support Supports up to 9216 bytov rámčeka size to improve performance of large data transfers. IGMP Snooping v1/v2 Improves network performance through multicast filtering, instead of flooding traffic on all ports. Link Aggregation Skupiny spolu s viacerými portmi až do maximálne osem (8) portov na kmeň automaticky využívajú Link Aggregation Control Protocol (LACP), alebo manuálne, na vytvorenie vysoko-bandwidth pripojenia k sieťovej backbone, ktoré pomáhajú prevádzať traffic bottlenecks. 8-portové modely na podporu 4 kmeňov, 24-portové modely na podporu 8 kmeňov, a 48-portové modely na podporu 16 kmeňov. LLDP/LLDP-MED (Media Endpoint Discovery) Definuje a štandardné zoskupenie LLDP, ktoré sú hodnotové hodnoty pre parametre suchého a QoS a VLAN pre automatické configu- ráciu siete siete siete pre sieťové telefóny. Address Resolution Protocol (ARP) Tabuľové ARP zobrazujú všetky IP adresy, ktoré majú byť resolved to MAC adresy, ich dynamicky alebo cez statické vstupné konfigurácie. Additional Features Accessed Through Local Web-Management Interface Top Event Dashboard Získajte správy pre kritické udalosti a dostupný prístup k aktuálnym logovým udalostiam. Quick Start-Up and VLAN Wizard Enables automatic configuring of initial settings such address IP, device information, and system time. VLAN wizard môže byť použitý pre nastavenie vnútrozemského VLAN ID a port membership. Access Control Lists (ACLs) Enable network traffic filtering by vytváral ACL, prispôsobuje ruky a výsledky criteria do ACL, a aplikuje ACL na povolenie alebo denne na jeden alebo viac interfaces alebo VLAN. Supports for 50 inbound IPv4 a ACL MAC s 480 ACEs. IPv6 Hosť Enables switches to managed and deployed at IPv6 network's edge. Rate Limiting Sety a enforces per-port indexy traffic limits na základe percentuálnych bodov alebo balíkov na sekundu. Protected Ports Porty v prístave izolácie skupiny sú navrhnuté z forwardingu Layer 2 traffic medzi porty v tejto skupine, providing dáta privacy and security. SCP a TFTP File Transfer Provides different mechanisms for secure file transfer cez SCP (Secure Copy Protocol) alebo TFTP. Dual Image Support Provide nezávislé primárne a sekundárne softvérové obrázky pre obnovu pri aktualizácii. User Account Management Password strength checking and aging feature provides enhanced security to user account administration to the local web management interface. Additionally, user account authentication môže byť teraz prostredníctvom RADIUS prístup k web-interface.' Secure Sockets Layer (SSL) Encrypts all HTTP traffic, bezpečný prístup k miestnej browser-based management of switch. SNMPv1, v2c, and v3 Facilitates remote management with SNMP management station that discovers and monitors the switch. Remote Monitoring (RMON) Provides advanced monitoring and reporting schopnosti pre štatistiky, history, alarms and events. RMON dáta sú retrieved z switch cez sieťový manažment platformy cez SNMP. Cable Diagnostic Tool Vytvorí mechanizmus na detekciu a report potenciálnych káblových väzieb, suchých a káblových opienok alebo káblov šortiek na vrkočových linkách, v prídavnom prostriedku na upevnenie dištancie na plochu a celkovú šírku kábla. Warranty, Service and Support Aruba Instant On Limited Lifetime Support poskytuje 24X7 telefónnu podporu pre prvých 90 dní a rozhovor podporu pre entire warranty period. Community support is included for the life of the product. Odpovedať na Hewlett Packard Enterprise website athpe.com/networking/servicespre detaily na service-level descriptions and product numbers. Pre detaily o servise a odpovede na čas vo vašom regióne, prosím kontaktujte naše miestne spoločnosti Hewlett Packard Enterprise sales office. Štandardy a protokoly (applies to all products in series) IEEE 802.3 10BASE-TIEEE 802.3u 100BASE-TXIEEE 802.3ab 1000BASE-TIEEE 802.3z 1000BASE-XIEEE 802.2af PoE 1 (PoE models only)IEEE 802.3at PoE 1 (PoE models only)IEEE 802.3x Flow controlIEEE 802.1Q VLANSIEEE 802.1p PriorityIEEE 802.3ad Link Aggregation Control Protocol (LACP)IEEE 802.1X Port Access AuthenticationIEEE 802.3az Energy Efficient EthernetIEEE 802.1D: Spanning Tree ProtocolIEEE 802.1W: Rapid Spanning Tree ProtocolIEEE 802.1S: Multiple Spanning Tree ProtocolIEEE 802.1AB Link Layer Discovery ProtocolDenial of service protectionCPU DoS protection
